Consumer microSD Cards
Specification
| Model No. | SD-810c | SD-831c | SD-832c | SD-801c | SD-829c |
|---|---|---|---|---|---|
| Status | Commercial | Commercial | Professional | Professional | Professional |
| Capacity | 4GB -8GB | 3D TLC: 16GB~512GB 3D pSLC: 4GB~64GB |
3D TLC:64GB~256GB 3D pSLC:16GB~128GB |
3D TLC: 128GB~1TB 3D pSLC: 32GB~512GB |
128GB~1TB |
| Interface & Speed Class | SD 3.0, 8-pin CL 10/U1/V10 |
SD6.0, 8-pin CL 10 /U3 / A1 / V30 |
SD6.0, 8-pin CL 10, U3, A2, V30, UHS-I |
SD6.0, 8-pin CL 10, U3,A1, V60/ V90, UHS-II |
SD6.0, 8-pin U3 / A2 / V30/UHS-I |
| Flash Type | MLC | 3D TLC / 3D pSLC | 3D TLC / 3D pSLC | 3D TLC / 3D pSLC | 3D QLC |
| Sequential Read/Write ( up to ) |
4GB: 95/30 MB/s 8GB: 95/60 MB/s |
3D TLC: 100/90 MB/s 3D pSLC: 100/90 MB/s |
3D TLC: 64GB: 100/50 MB/s 128 – 256GB: 100/90 MB/s 3D pSLC: 100/90 MB/s |
3D TLC: 280/150 MB/s 3D pSLC: 280/250 MB/s |
100/90 MB/s |
| Op. Temperature | -25°C~85°C | ||||
| MTBF(hours) | 3,000,000hrs | ||||
| Voltage | 2.7V-3.6V | ||||
| Weight | 2 g (0.07 oz) | ||||
| Dimension (LxWxH/mm) |
15.0 x 11.0 x 1.0 | ||||
| Application |
|
|
|
|
|
